Requirements Product Specification/mm Co:Spinel Ø6×1 mm Process Indicators Material: Co:Spinel crystal Dimensions, mm: Ø6 Dimensions tolerance, mm: +0/-0.2 Thickness, mm: 1 Thickness tolerance, mm: ±0.2 End surfaces confirguration: Plano/Plano Initial transmission: 90 +/-0.5 % Surface quality, S-D: 20-10 Parallelism error: < 15 arcsec Protective chamfer: 0.2 mm x 45° Clear aperture, %: >90 % Pictures
Case
Cr:ZnSe crystal case (1) – 2×4×5 mm
Requirements Product Specification/mm Cr:ZnSe 2×4×5 mm Process Indicators Material: Polycrystalline Cr:ZnSe crytal Size: 2*4*5 mm (W*H*L) Optically polished sides: 2*4 mm facets (two sides) Scratch/dig: 40/20 Parallelism: <30 arcsec Clear aperture: 90% of the side Transmission: 3.9% through 5 [email protected] nm Orientation Tolerence: < 0.5° Thickness/Diameter Tolerance: ±0.1 mm Surface Flatness: <λ/8 Perpendicular: 15ˊ Chammfer: […]
Yb:CaF2 crystal case (5) – 3×3×4 | 2×7×6mm
Requirements Product Specification/mm Yb:CaF2 3×3×4 mm Yb:CaF2 2×7×6mm Process Indicators Material: Yb:CaF2 crystalDoping level: 5%Dimension,mm: 3×3(+0/-0.05) mm2Thicnkess, mm: 4(±0.1) mmOrientation: [111] +/-0.1° 2-side polished on 3×3 mm2Parallelism: <10”Perpendicularity : <5′ Flatness: λ/[email protected] quality: 20/10(MIL-O-13830A)Wavefront distortion: λ/[email protected]:S1/S2: AR @[email protected] 980 nm, AOI = 0° With a 1 deg wedge Crystals: Yb(3%):CaF2Doping level: 3%Orientation: as per attached […]
Nd:YLF crystal case 1 – Φ5×20 | Φ3×20 mm for 1053 nm Laser
Requirements Product Specification/mm Nd:YLF Φ5×20 mm Nd:YLF Φ3×20 mm Process Indicators Material: Nd:YLF Dimensions, mm: Φ5, Φ3 Dimensions tolerance, mm: ±0.1 Thickness, mm: 20 Thickness tolerance, mm: ±0.1 Coating: AR/AR 808+1053 nm Orientation Tolerence: < 0.5° Surface Flatness: <λ/[email protected] Wavefront Distortion(WFD): <λ/[email protected] Surface Quality : 20/10 Parallel : 30〞 Perpendicular: 15ˊ Clear Aperture: >90% Chammfer: […]
Co:Spinel crystal case (6) – 4.3×4.3 mm
Requirements Product Specification/mm Co:Spinel 4.3×4.3×(0.8-1.5) mm Process Indicators Material: Co:Spinel Dimensions, mm: 4.3×4.3 Dimensions tolerance, mm: +0/-0.2 Thickness, mm: 0.8-1.5 Thickness tolerance, mm: ±0.2 T0=92.5±0.1%@1540 nm 2-side polishing Uncoated End surfaces confirguration: Plano/Plano Surface quality, S-D: 40-20 Parallelism error: < 15 arcsec Protective chamfer: 0.2 mm x 45° Clear aperture, %: >90 % Pictures
Er,Cr,Yb:Glass case (4) – Ø4×105.5 mm for 1535nm laser
Requirements Product Specification/mm Er,Cr,Yb:Glass Blank rod φ4×105.5 mm Process Indicators Custom grown blank rod Material: Er,Cr,Yb:Glass Size: φ4*105.5mm blank CA: >95% Barrel finish: 45-65 micro inch Pictures
