Cr:YAG crystal case (5) – φ7×2.8 mm

Requirements

Product

Specification/mm

Cr:YAG

φ7×2.8 mm

Process Indicators

  • Material: Cr:YAG crystals
  • Diameter: φ7mm
  • Initial Transmission: T0 = 40%@1064nm
  • Dimensional tolerances: diameter ± 0.5mm
  • Barrel finish: Ground finish 400 # Gmt
  • Parallelism: ≤ 20 “
  • Perpendicularity: ≤ 15 ′
  • Flatness: <λ/10
  • Surface Quality: 20/10 (MIL-O-13830A)
  • Wavelength: 950 nm ~ 1100nm
  • Double-sided AR Coating Reflectivity: ≤0.2% (@ 1064nm)
  • Damage threshold: ≥ 500MW / cm2 10ns, 1Hz at 1064nm
  • Chamfer: <0.1 mm @ 45°

Pictures

cr-yag-case-13
cr-yag-case-12
