Specifications
| Product | Size/mm | Quantity /pcs |
| Er:YAP | 2*5*8mm | 12 |
| Er:YAP | 10*10*3mm | 4 |
Processing Requirements
- Doping concentration: 5.0at%
- Clear Aperture: 2mm x 5mm
- Parallelism: <10 “
- Perpendicular: <5′
- Both ends are flat
- Surface Flatness: < λ /[email protected]
- Surface Quality: better than grade II
Coating Requirements
AR/[email protected] 980nm&2700-3000nm，R<1.5%
Inspection Report
| Items | Value Specified and Tolerance | Quantity /pcs | OK | NG |
| Size | 2*5*8mm | 12 | 12 | |
| Surface Quality | 40-20 | 12 | 11 | 1 |
| Surface Flatness | λ /[email protected] | 12 | 12 | |
| Clear Aperture | >90% | 12 | 12 | |
| Chamfer | 0.1mm | 12 | 12 | |
| Chip | <0.05mm | 12 | 12 |
Coating Test Curve
 |
| Reflection spectrumof Er:YAP in 960nm-980nm |
 |
| Reflection spectrumof Er:YAP in2700nm-3000nm |
Product Images
