LBO nonlinear crystal case (3) – 3×3×10 | 3×3×20 | 3×3×30 mm

Requirements

Product

Specification/mm

LBO crystal

3*3*10mm

LBO crystal

3*3*20mm

LBO crystal

3*3*30mm

Process Indicators

  • Material: LBO crystal
  • Clear aperture: >90%
  • Thickness/Diameter Tolerance: ±0.1 mm
  • Orientation: theta – 90 deg, Phi – 5.4 deg
  • Orientation Tolerence: < 0.5°
  • Surface Quality: 20/10
  • Parallel: 30〞
  • Perpendicular: 15ˊ
  • Surface Flatness: <λ/8@632nm
  • Wavefront Distortion(WFD): <λ/4@632nm
  • 2-side polishing(3*3 mm)
  • Coating: S1/S2AR/AR@1020 –1180 nm&530 -590nm on both side

Pictures

lbo-case-8
lbo-case-7
