N31 Nd:Glass case (4) – φ50×267 mm

Requirements

Product

Specification/mm

N31 Glass

φ50×267 mm

Process Indicators

  • Glass Type: N31
  • Diameter: 50.0 (+0/-0.05) mm
  • Length: 267 (±2) mm
  • Doping: 0.5 (±0.03) wt. %
  • Wedge ends: 2.0° ± 5 arc-min
  • End parallelism: ≤ 1 arc-min
  • Chamfer: 0.25-1 mm face width at 45 (±15) degrees
  • Clear aperture: 46.0 mm
  • Surface flatness: ≤λ/4 @ 633 nm
  • Surface quality: ≤10/5 scratch/dig
  • Barrel finish: fine ground, 30 μm grit size
  • Transmitted wavefront: ≤ λ/6 P-V @ 633 nm with gradient ≤λ/10/cm
  • Coating: AR/AR R<0.25% @ 1053 nm, 0°, damage > 7 J/cm2 for 1 ns @ 1053 nm

Pictures

N31-Nd:glass-case-13
N31-Nd:glass-case-14
