TGG crystal case (1) – φ13×4 mm / 10×10×10 mm for Faraday rotator and isolator

Requirements

Product

Specification/mm

TGG

TGG Disk
Size: φ13x4mm
Orientation: 111
Both apertures: Optical polished (flatness:lambda/5@633nm approx.), uncoated
Barrel: Fine ground

TGG

TGG Cube
Size: 10x10x10mm
Orientation: 111
4 faces (2 x facing faces): Optical
polished (flatness: lambda/5@633 nm approx.), uncoated
Other 2 faces (1 x facing faces): Fine ground

Process Indicators

  • Thickness/Diameter Tolerance ±0.10 mm
  • Surface Quality ’40/20
  • Parallel 1ˊ
  • Perpendicular 30ˊ
  • Clear Aperture >90%
  • Chammfer <0.2×45°

Add Your Heading Text Here

tgg case 1
tgg case 2
tgg case 3
tgg case 4
