BBO crystal case (3) – 4×4×20 mm

Requirements

ProductSpecification/mm
BBO4*4*20 mm

Process Indicators

  • Size: 4*4*20mm, z-cut
  • AR/AR@1030nm, R<0.1%
  • Electrodes on X faces (with Au/Cr electrodes.)
  • Ends 0/0 deg
  • Length between electrodes: 4.0 +0.0/-0.2 mm
  • Length between grinded sides: 4.0 +/-0.1 mm
  • Length tolerances: +0.5/-0.2mm
  • Orientation tolerances: +/-30 arcmin
  • Surface Quality: 10-5 s/d
  • Surface flatness: L/8@633nm
  • Wavefront distortion: Better than L/8@633nm
  • Parallelism: better than 30 arcsec
  • Perpendicularity: better than 10 arcmin
  • Contrast without voltage: better than 1:1000
  • Coating on both 4*4 mm sides: AR<0.1% @1030nm
  • Electrodes on both X 4*20 mm faces
  • Electrodes as close to 4 mm side as possible. Not more than 0.5mm
  • No gold on chamfers
  • Damage threshold: >7J/cm2@1064nm, 10ns,10HZ



Pictures

BBO-4×4×20
